The diameter of the steel wire to be cut is 2.0-4.0mm

Cutting length range: over 80mm

Feeding speed: Adjustable speed 50-120 meters per minute (the smaller the wire diameter, the faster the speed; the shorter the length, the slower the speed)

Length error: ±0.5mm

Straightening wire: Ordinary carbon steel wire

Feeding rack: 1000*300*150

Wire feeding motor: 1.5kw servo motor

Straightening motor: 3.0KW/2880r

Flying cutting servo motor: 2.8KW cutting servo motor

Guide rail module: Taiwan

Number of wire feeding groups: 2 groups (5 pairs of wheels)

Control screen: Touch screen

Number of straightening blocks: 9

Wire range: 2.0-4.0mm iron, stainless steel, carbon steel.

Rack dimensions (length * width * height) : 2350*750*1550 (mm)
